Large format uniform illumination, mainly for perspective contour imaging
Variety of sizes for uniform illumination of large areas
Measurement of various dimensions
Burr inspection of metal parts
Fill level inspection
Electronic components, IC appearance inspection
XL |
- |
BRL |
- |
20*20 |
- |
R |
① |
|
② |
|
③ |
|
④ |
① |
Brand XISPEK LIGHING |
② |
BRL - Bottom Backlight Series, BRD2 Open Backlight Series |
③ |
Light-emitting area: length*width Unit: mm Customizable |
④ |
Light source color (R is red, B is blue, W is white, G is green, IR is infrared, UV ultraviolet) |
Model |
Voltage/Power |
Product Size |
|||
R |
B G W |
Length mm |
Width mm |
Height mm |
|
XL-BRL-20X20 |
24V/1.0W |
24V/1.7W |
52 |
32 |
12 |
XL-BRL-30X30 |
24V/1.23W |
24V/3.5W |
43 |
41 |
12 |
XL-BRL-30X70 |
24V/2.85W |
24V/4.08W |
88 |
39 |
12 |
XL-BRL-50X50 |
24 V/4.4 W |
24V/4.89W |
78 |
30.5 |
12 |
XL-BRL-60X60 |
24V/6.2W |
24V/6.5W |
74 |
72 |
12 |
XL-BRL-160X400 |
24V/36.7W |
24V/48.9W |
429 |
169 |
30 |
XL-BRL-180X120 |
24V/14.7W |
24V/15.9W |
210 |
129 |
30 |
XL-BRL-560X560 |
24V/179.8W |
24V/239.6W |
593 |
573 |
30 |
XL-BRD2-200X200 |
24V/20.6W |
24V/30.3W |
234 |
234 |
10.5 |
XL-BRD2-350X350 |
24V/28.3W |
24V/43.2W |
384 |
384 |
10.5 |
XL-BRD2-600X400 |
24V/38.8W |
24V/64.8W |
634 |
434 |
10.5 |
