High-definition fixed-focus industrial lenses developed specifically for the machine vision field
Support a wide range of focusing distance, especially optimized for close-up imaging
Temperature-compensated design for stable imaging performance at -10°C to +50°C
Available from cost-effective F2.0 to high throughput F1.4 aperture
Low distortion design, low image distortion
Compact design for easy integration and installation
1/1.8"inch lens
|
Model |
Focal length |
Iris range (F. no) |
Sensor size |
Angle of view |
TV distortion |
Extreme Distance |
Mount |
Filfer screw size |
||
|
1/1.8" |
1/2.5" |
1/3" |
||||||||
|
XAL-06A20M5M |
6 |
2 |
1/1.8" |
236.6x177.4 |
189.28x144.05 |
157.73*120.05 |
<0.1% |
0.1M |
M25.5xP0.5 |
C Mount |
|
XAL-08A20M5M |
8 |
2 |
1/1.8" |
182.2x136.6 |
145.76x110.92 |
121.47x92.44 |
<0.1% |
0.1M |
M25.5xP0.5 |
C Mount |
|
XAL-12A20M5M |
12 |
2 |
1/1.8" |
123x92.3 |
98.4x74.95 |
82x62.46 |
<0.3% |
0.1M |
M25.5xP0.5 |
C Mount |
|
XAL-16A20M5M |
16 |
2 |
1/1.8" |
89.5x67.1 |
71.6x54.49 |
59.67x45.41 |
<0.1% |
0.1M |
M25.5xP0.5 |
C Mount |
|
XAL-25A20M5M |
25 |
2 |
1/1.8" |
53.3x40 |
42.64x32.48 |
35.53x27.07 |
<0.1% |
0.1M |
M25.5xP0.5 |
C Mount |
|
XAL-35A20M5M |
35 |
2 |
1/1.8" |
37.3x28 |
29.84 x 22.74 |
24.87x18.95 |
<0.1% |
0.2M |
M25.5xP0.5 |
C Mount |
|
XAL-50A28M5M |
50 |
2.8 |
1/1.8" |
36.1 x27.1 |
28.88x22 |
24.07x18.34 |
<0.05% |
0.3M |
M28.5xP0.5 |
C Mount |
2/3"inch lens
|
Model |
Focal length |
Iris range (F. no) |
Sensor size |
Angle of view |
TV distortion |
Extreme Distance |
Mount |
Filfer screw size |
||
|
2/3" |
1/2" |
1/3” |
|
|||||||
|
XAL-08B14M5M |
8 |
1.4 |
2/3" |
227.7x170 |
165.6x123.64 |
124.2x92.73 |
< 1% |
0.1M |
M37xP0.5 |
C Mount |
|
XAL-12B14M5M |
12 |
1.4 |
2/3" |
149.2x111.9 |
108.51 x 81.38 |
81.38x61.03 |
<-0.8% |
0.15M |
M30.5xP0.5 |
C Mount |
|
XAL-16B14M5M |
16 |
1.4 |
2/3" |
116.9x87.3 |
85.02x63.49 |
63.76x47.62 |
<0.1% |
0.1M |
M30.5xP0.5 |
C Mount |
|
XAL-25B14M5M |
25 |
1.4 |
2/3" |
70.7 x 52.7 |
51.42 x 38.33 |
38.56 x 28.75 |
<0.2% |
0.2M |
M30.5xP0.5 |
C Mount |
|
XAL-35B14M5M |
35 |
1.4 |
2/3" |
54.7 x 40.9 |
39.78x29.75 |
29.84 x 22.31 |
<-0.8% |
0.2M |
M37xP0.5 |
C Mount |
|
XAL-50B14M5M |
50 |
1.4 |
2/3" |
49.7 x 37.3 |
36.15 x 27.13 |
27.11 x20.35 |
<-0.8% |
0.3M |
M37xP0.5 |
C Mount |
